What is this? #

The Inlab Networks PCAP-Suite is an XDP accelerated set of tools which allows to capture, control and record Layer2 traffic at rates up to 400GbE.

The PCAP-Suite is our packet capture reference implementation in terms of speed, flexibility, precision and reliability.

It consists of the following programs:

ixdp #

• XDP zero-copy ring management with scalable number of concurrent threads
• RPCL managed (Reverse Polish Configuration and Control Language)
• Layer2 / Ethernet metadata statistics and control
• Selective packet capture and forwarding to fast shared memory queues
• IP address queues to allow DNSBL processing
• Full nested VLAN transparency
• Built-in extended MAC vendor database
• Statistics export

collect #

• Collects packets from ixdp fed SHM queues
• Writes standard PCAP format to a file or stdout
• Operates on SHM queues (instead of NICs)
• what’s actually in a particular SHM queue is determined by the ixdp configuration and Layer2 metadata

harvest #

• Collects (harvestes) packets from the ixdp fed SHM queues
• Manages and fills a directory with PCAP files following the configured retention and filename parameters
• RPCL controlled, multiple background instances in parallel

idnsbl #

• Collects IP addresses from ixdp fed IPaddr queues
• Resolves and checks a configurable set of DNSBL resources
• Feeds the results back to ixdp which updates its in-memory block and allow-lists
• RPCL controlled

control #

• generic frontend to connect interactively to the CLI of background processes
